LED Panel Lighting (Backlit 30 x 30 cm)
LED panel lighting is an innovative and highly efficient lighting solution that offers numerous benefits for both residential and commercial applications. These panels are designed to replace traditional grille fixtures,have a longer lifetime, reducing maintenance costs and the need for frequent replacements.
Moreover, they emit minimal heat, making them an ideal choice for spaces where temperature control is crucial. The adjustable color temperature feature allows users to easily switch between warm and cool lighting tones, catering to different preferences and creating the desired ambiance.
Features:
- Structure:Al Frame+Diffuser Plate+Lens+Back Plate
- External Isolated Driver, Customized Dimming Function
- Bridgelux/Samsung/Philips/Osram/Epstiar SMD 2835
- CCT:3000K/4500K/5500K/6500K,RGB is available
- IP Rating: IP 20/IP 65 Waterproof
- Beam Angle 110 Deg(standard)
- Surge 2.0 KV,Connector Safe and Reliable Design
- Easy To Install,Suspending & Ceiling mounted & Recessed
- Thickness :31 mm
- Mosquito and Dust Prevention
- Warranty: 3/5 Years
- Compliance: CE RoHS Certified
Model:ST-LPL-3030-6BL
- Wattage:6 W
- Light Efficiency(lm/w):100/120/150
- Volt:DC 12/24 V or AC 85-220 V
- Frequency:50/60 Hz
- PF >0.9
- CCT:2800 K-6500 K;RGB
- CRI (Ra)>80
- IP Grade:20/65
- Size:30 x 30 cm
- Inch:11.6″ x 11.6″
- Thickness:31 mm(1.2″)
- Packing:20 pcs/carton
Model:ST-LPL-3030-9BL
- Wattage:9 W
- Light Efficiency(lm/w):100/120/150
- Volt:DC 12/24 V or AC 85-220 V
- Frequency:50/60 Hz
- PF >0.9
- CCT:2800 K-6500 K;RGB
- CRI (Ra)>80
- IP Grade:20/65
- Size:30 x 30 cm
- Inch:11.6″ x 11.6″
- Thickness:31 mm(1.2″)
- Packing:20 pcs/carton
Model:ST-LPL-3030-11BL
- Wattage:11 W
- Light Efficiency(lm/w):100/120/150
- Volt:DC 12/24 V or AC 85-220 V
- Frequency:50/60 Hz
- PF >0.9
- CCT:2800 K-6500 K;RGB
- CRI (Ra)>80
- IP Grade:20/65
- Size:30 x 30 cm
- Inch:11.6″ x 11.6″
- Thickness:31 mm(1.2″)
- Packing:20 pcs/carton
Model:ST-LPL-3030-13BL
- Wattage:13 W
- Light Efficiency(lm/w):100/120/150
- Volt:DC 12/24 V or AC 85-220 V
- Frequency:50/60 Hz
- PF >0.9
- CCT:2800 K-6500 K;RGB
- CRI (Ra)>80
- IP Grade:20/65
- Size:30 x 30 cm
- Inch:11.6″ x 11.6″
- Thickness:31 mm(1.2″)
- Packing:20 pcs/carton
More Details of 30 x 30 cm LED Panel Lighting
- AL Frame(6063 Al)
- Diffuser Plate:PC/ Acrylic (PMMA) or PS is optional
- LED Beads+ Lens+PCB(high thermal conductivity aluminum substrate)
- Back Plate: Metal Material, 2.5-3mm thickness.
Led Driver: Over-voltage, over-temperature, anti-surge protection brand isolated external driver
Different order quantities, shipping methods and parameter requirements will be different prices, please contact our sales for an accurate quotation.
Installation of LED panel light
LED panel lights are easy to install. It has several different installations:built-in installation, ceiling-mounted installation(exposed installation) and suspended installation.
Built-in and ceiling-mounted installations are ideal for most environments, such as hospitals, residences, and office areas.
Suspended installation is more commonly used in large space environments such as bars, restaurants, and stations.
Customized Requirement is Optional:
- Light Source LED Beads Quantity
- LED Chip Brand
- Color Temperature
- Driver: TRIAC/0-10 V/DALI dimmable
- DC12/24V or AC 110/220V is optional
- Your Logo and Package Design
- Emergency Backup (30% power with 1 / 2/ 3 hours duration)
